Optic light source-D

Description

optic light source stable light source are mainly used for continuous optical signal power measurement, optical fiber link on-off test, link fault diagnosis and link loss test. It adopts thermal molding process, which is beautiful and durable. The whole machine has the function of adjustable output power, the maximum adjustment is 6dB. hand-held stable light source and optical power meter are used together. They are widely used in optical fiber construction and maintenance, optical fiber communication, optical fiber sensing, Optical CATV and other fields. They can also be used to test the insertion loss and splitting ratio of passive devices such as optical splitter, circulator, optical coupler and optical switch.





Features:



◆Support automatic shutdown
◆Support backlight switch
◆Lithium battery, portable battery charging
◆Support SM/MM integratio
◆Power is adjustable, the range is 6dB by 1dB step
◆Support CW and multiple modulation outpu
◆1650nmSupport wavelength customization
◆Customized 1625nm/1650n





Parameters:



Wavelengths(nm) 850/1300 1300/1310/1550
Fiber type 62.5/125μm 9/125μm
Emitter Type FP-LD,LED or others please specify
Typical Output Power (dBm) -5dBm for LD, -20dBm for LED
Power regulation 0-6dB ,1dB step
Output Stability   ±0.02dB/ 8hours
Modulation Frequencies CW,270Hz,1KHz,2KHz
Optical Connector FC/SC/2.5mm
Power Supply Alkaline Battery(3 AA 1.5V batteries)
Battery Operating Time(hour) 72
Operating Temperature(℃) -10~+60
Storage Temperature(℃) -25~+70
