Duct drop cable

Add to wishlist

Description

Applications:



◆Mainly used in building aerial and duct access cabling





Features:



◆Good mechanical and environmental characteristics;
◆The mechanical characteristics of jacket meet the requirements of relevant standards;
“◆Easy to splice and convenient laying, and with big capacity data
transmission;”
◆Meet various requirements of market and clients.





Cable Parameters:



Fiber Count Diamension(mmmm) Weight(kg/km) Tensile Strength(N) Crush Resistance(N/100mm) Bending Radius(mm)
Short Term Long Term Short Term Long Term Dynamic Static
1-4 7.0 42 500 200 1000 500 20D 10D





Options:



◆Fiber Type: G.652 G.655 or G.657 single-mode fiber, A1a or A1b multi-mode fiber, or other types of fiber;
◆Jacket Material: Environmental low smoke zero halogen flame retardant polyolefin (LSZH), or other contracted material;
◆Jacket Color: (Including color of fiber) meets the requirements of relevant standards, or other contracted color;
◆Cable Dimension: The nominal cable dimension, or other contracted dimension;
◆Delivery Length: 1km or 2km, or other contracted length;
