Distribution cable

Add to wishlist

Description

Applications:



◆Used in indoor cabling, especially used as distribution cable;
◆Used as interconnect lines of equipments, and used in optical
connections in optical communication equipment rooms and
distribution frames;
◆Used in pigtails and patch cords





Features:



◆Good mechanical and environmental characteristics;
◆Flame retardant characteristics meet the requirements of relevant standards;
◆The mechanical characteristics of jacket meet the requirements of relevant standards;
◆Soft, flexible, easy to lay and splice, and with big capacity data transmission;
◆Meet various requirements of market and clients.





Cable Parameters:

Outer Diameter(mm) Weight(kg/km) Cable Code Tensile Strength(N) Crush Resistance(N/100mm) Bending Radius(mm)
Short Term Long Term Short Term Long Term Dynamic Static
4.8±0.3 18 4 440 130 1000 300 20D 10D
5.1±0.3 23 6 440 130 1000 300 20D 10D
5.6±0.3 31 8 440 130 1000 300 20D 10D
6.2±0.3 36 12 440 130 1000 300 20D 10D
8.1±0.3 57 24 200 660 1000 300 20D 10D





Options:



◆Fiber Type: G.652 G.655 or G.657 single-mode fiber, A1a or A1b multi-mode fiber, or other types of fiber;
◆Jacket Material: Environmental low smoke zero halogen flame retardant polyolefin (LSZH), or other contracted material;
◆Jacket Color: (Including color of fiber) meets the requirements of relevant standards, or other contracted color;
◆Cable Dimension: The nominal cable dimension, or other contracted dimension;
◆Delivery Length: 1km or 2km, or other contracted length;
